DAISO | G-Tape creasing matrix

Cutters for creasing matrix (G-Tape)

G-Tape matrix cutters

VS-IV (G-Tape matrix cutter)

VS-IV matrix cutter chamfer taper cut daiso

Features

  • The world’s first V-cut and chamfering cut in one action.
  • No more trimming job. Save time of machine downtime.
  • International patented matrix cutter. Only one matrix cutter in the world.
    • Optional scale 700mm available.
    • Optional locator stopper arrange minimum 10mm cut ( standard cut 20mm).
    • Anti-adhesive coated cutter is also available.
    • This matrix cutter is exclusive for G-Tape creasing matrix only.

Specification

chamfering
photo__p035_03



NameSizeWeight
VS-Ⅳ740㎜ × 90㎜ × 310㎜
scale 500㎜
6.8Kg

Matrix cutters

メリーカッター

Merry cutter

Features

  • Scissors for G-Tape and Corks etc.. Heavy-duty with less power.

Specification

photo__p035_05

NameSizeWeight
Merry cutter210㎜ × 20㎜ × 80㎜340g

Gカッター

G-cutter

Features

  • G-Tape matrix cutter for V-cut.

Specification

NameSizeWeight
G-Cutter 500mm650㎜ × 65㎜ × 146㎜ (excluding lever handle)7.1Kg

Gカッター替刃

Blade spare parts for G-cutter

Features

  • Replacing blade. 2 types ( standard and acute angle).

Specification

NameDescription
Spare blade for G-CutterStandard blade 42°
Acute blade 40°

GカッターDX

G-cutter DX

Features

  • G-Tape matrix cutter for V-cut. G-Tape scraps go down.

Specification

NameSizeWeight
G-Cutter DX967㎜ × 65㎜ × 180㎜ (excluding lever handle)10.2Kg
